OFFSET SQUAREBRELLA WITH ROTO HEAD

The Offset & Canti Brellas are available in square and hexagon designs featuring a rotatable upper structure for maximum shade. They are durable, permanent shade structures that come in a variety of UV-protecting fabric colors and powder-coated steel frames that are perfect for shuffleboard, bocce ball, seating and pool areas.

BreezeBrellas® are ideal for:

Playgrounds
Sandboxes
Outdoor Dining Areas
Picnic Areas
Pools & Aquatic Centers
Hotels and Resorts

KEY:

Not actual foundations (vary per application)
Top = Top of footing
FF = Top of the finish surface
V/A = Varies per application
RF = Roof Pitch

Square shade structure anchors layout blueprint.

Direct embedment column is standard
Installation with anchor bolts available (inquire)
F1554-GRD 36 or 55 threaded rod-nuts not supplied
Size Ø and length per design and application
Level washers and non-shrink grout not supplied

ANCHOR SYSTEM

Brella Size	Roof Pitch (RF)
10 x 10	24”
11 x 11	27”
12 x 12	30”
13 x 13	33”
14 x 14	35”
15 x 15	38”

NOTES:

Brella boom arm may be rotated as desired
Brella head may be rotated as desired
Roto head assembly with easy rotate
Surface mount column installation optional (inquire)

Offset SquareBrella elevation blueprint.

PLAN LAYOUT

FRONT ELEVATION

PLAN LAYOUT

FRONT ELEVATION

NOTES:

Installation to be completed in accordance with manufacturer’s specifications.
Do not scale drawing.
This drawing is intended for use by architects, engineers, contractors, consultants & design professionals only.
This drawing may not be used for construction.
All information contained herein is subject to change by Apollo Sunguard.
Structural members & foundations are designed according to applicable local codes & latest edition of IBC as per ICC.
Shade fabric designed for easy & quick removal. QRS – Quick Release System
Contact Apollo Sunguard for customization.
